Burton Power now has a short body version of its normal .75″ master cylinder.

The brake/clutch master cylinder is ideal for compact installations. It is 25mm shorter than the normal BRK016 master cylinder, with a body casting length of just 80mm as measured from the mounting flange.

The master cylinder has a 7/16″UNF inlet, a 3/8″UNF outlet, 57mm mounting bolt centres and a M8 threaded rod.

The short body master cylinder can be ordered as BRK075 and at just £51.00 each incl. VAT it is an affordable way to solve the problem of a cramped engine compartment in a modified car, competition car or kit car.

for further details contact Burton Power on 0208 554 2281
www.burtonpower.com

If you are looking to keep your early classic Ford original, the time will come when you need to source new brake cylinders for those drum brakes. Fortunately, Burton Power can now offer front wheel cylinders that will fit several British drum brake equipped Fords.

The wheel cylinders can be ordered as part numbers WC4923 (left hand side) and WC4924 (right hand side) and retail at £12.95 incl. VAT each. Two cylinders were used on each side and they all had a bore of 19.05mm.

Applications:
Ford Anglia 100E 02/1957-1959
Ford Cortina Mk1 1.2/1.5 1962-10/1964
Ford Escort Mk1 1.1/1.3 1968-1974
Ford Prefect 107E 1.0 1959-1961

for further details contact Burton Power on 0208 554 2281
www.burtonpower.com
